Overview

Teaching: 0 min
Exercises: 0 min

Questions

• How can I get rid of sequence data that doesn’t meet my quality standards?

Objectives

• Clean FASTQ reads using Trimmomatic.

• Select and set multiple options for command-line bioinformatic tools.

• Write for loops with two variables.

Recorded Lesson:

Module 2 | Lesson 4 | Trimming and Filtering

Cleaning Reads

In the previous episode, we took a high-level look at the quality of each of our samples using FastQC. We visualized per-base quality graphs showing the distribution of read quality at each base across all reads in a sample and extracted information about which samples fail which quality checks. Some of our samples failed quite a few quality metrics used by FastQC. This doesn’t mean, though, that our samples should be thrown out! It’s very common to have some quality metrics fail, and this may or may not be a problem for your downstream application. For our variant calling workflow, we will be removing some of the low quality sequences to reduce our false positive rate due to sequencing error.

We will use a program called Trimmomatic to filter poor quality reads and trim poor quality bases from our samples.

Trimmomatic Options

Trimmomatic has a variety of options to trim your reads. If we run the following command, we can see some of our options.

$ trimmomatic

Which will give you the following output:

Usage:
       PE [-version] [-threads <threads>] [-phred33|-phred64] [-trimlog <trimLogFile>] [-summary <statsSummaryFile>] [-quiet] [-validatePairs] [-basein <inputBase> | <inputFile1> <inputFile2>] [-baseout <outputBase> | <outputFile1P> <outputFile1U> <outputFile2P> <outputFile2U>] <trimmer1>...
   or:
       SE [-version] [-threads <threads>] [-phred33|-phred64] [-trimlog <trimLogFile>] [-summary <statsSummaryFile>] [-quiet] <inputFile> <outputFile> <trimmer1>...
   or:
       -version

This output shows us that we must first specify whether we have paired end (PE) or single end (SE) reads. Next, we specify what flag we would like to run. For example, you can specify threads to indicate the number of processors on your computer that you want Trimmomatic to use. In most cases using multiple threads (processors) can help to run the trimming faster. These flags are not necessary, but they can give you more control over the command. The flags are followed by positional arguments, meaning the order in which you specify them is important. In paired end mode, Trimmomatic expects the two input files, and then the names of the output files. These files are described below. While, in single end mode, Trimmomatic will expect 1 file as input, after which you can enter the optional settings and lastly the name of the output file.

The last thing trimmomatic expects to see is the trimming parameters:

We will use only a few of these options and trimming steps in our analysis. It is important to understand the steps you are using to clean your data. For more information about the Trimmomatic arguments and options, see the Trimmomatic manual.

However, a complete command for Trimmomatic will look something like the command below. This command is an example and will not work, as we do not have the files it refers to:

$ trimmomatic PE -threads 4 SRR_1056_1.fastq SRR_1056_2.fastq  \
              SRR_1056_1.trimmed.fastq SRR_1056_1un.trimmed.fastq \
              SRR_1056_2.trimmed.fastq SRR_1056_2un.trimmed.fastq \
              ILLUMINACLIP:SRR_adapters.fa SLIDINGWINDOW:4:20

In this example, we’ve told Trimmomatic:

Multi-line commands

Some of the commands we ran in this lesson are long! When typing a long command into your terminal, you can use the \ character at the end of a line to separate code chunks onto separate lines. This can make your code more readable. Notice how \ is used in the Trimmomatic command above. It is a single command written on 4 lines.

Running Trimmomatic

Now we will run Trimmomatic on our data. To begin, navigate to your untrimmed_fastq data directory:

$ cd ~/home/your_username/data/dc_workshop/data/untrimmed_fastq

We are going to run Trimmomatic on one of our paired-end samples. While using FastQC we saw that Nextera adapters were present in our samples. The adapter sequences came with the installation of trimmomatic, so we will first copy these sequences into our current directory. By using ./ at the end of the command, our command says to copy the adapters and put them right here in our current directory.

$ cp /opt/conda/share/trimmomatic-0.38-0/adapters/NexteraPE-PE.fa ./

We will also use a sliding window of size 4 that will remove bases if their phred score is below 20 (like in our example above). We will also discard any reads that do not have at least 25 bases remaining after this trimming step. This command will take a few minutes to run.

$ trimmomatic PE SRR2589044_1.fastq.gz SRR2589044_2.fastq.gz \
                SRR2589044_1.trim.fastq.gz SRR2589044_1un.trim.fastq.gz \
                SRR2589044_2.trim.fastq.gz SRR2589044_2un.trim.fastq.gz \
                SLIDINGWINDOW:4:20 MINLEN:25 ILLUMINACLIP:NexteraPE-PE.fa:2:40:15

TrimmomaticPE: Started with arguments:
 SRR2589044_1.fastq.gz SRR2589044_2.fastq.gz SRR2589044_1.trim.fastq.gz SRR2589044_1un.trim.fastq.gz SRR2589044_2.trim.fastq.gz SRR2589044_2un.trim.fastq.gz SLIDINGWINDOW:4:20 MINLEN:25 ILLUMINACLIP:NexteraPE-PE.fa:2:40:15
Multiple cores found: Using 2 threads
Using PrefixPair: 'AGATGTGTATAAGAGACAG' and 'AGATGTGTATAAGAGACAG'
Using Long Clipping Sequence: 'GTCTCGTGGGCTCGGAGATGTGTATAAGAGACAG'
Using Long Clipping Sequence: 'TCGTCGGCAGCGTCAGATGTGTATAAGAGACAG'
Using Long Clipping Sequence: 'CTGTCTCTTATACACATCTCCGAGCCCACGAGAC'
Using Long Clipping Sequence: 'CTGTCTCTTATACACATCTGACGCTGCCGACGA'
ILLUMINACLIP: Using 1 prefix pairs, 4 forward/reverse sequences, 0 forward only sequences, 0 reverse only sequences
Quality encoding detected as phred33
Input Read Pairs: 1107090 Both Surviving: 885220 (79.96%) Forward Only Surviving: 216472 (19.55%) Reverse Only Surviving: 2850 (0.26%) Dropped: 2548 (0.23%)
TrimmomaticPE: Completed successfully

Exercise

Use the output from your Trimmomatic command to answer the following questions.

1) What percent of reads did we discard from our sample? 2) What percent of reads did we keep both pairs?

Solution

1) 0.23% 2) 79.96%

You may have noticed that Trimmomatic automatically detected the quality encoding of our sample. It is always a good idea to double-check this or to enter the quality encoding manually.

We can confirm that we have our output files:

$ ls SRR2589044*

SRR2589044_1.fastq.gz       SRR2589044_1un.trim.fastq.gz  SRR2589044_2.trim.fastq.gz
SRR2589044_1.trim.fastq.gz  SRR2589044_2.fastq.gz         SRR2589044_2un.trim.fastq.gz

The output files are also FASTQ files. The output .trim files should be smaller than our input file, because we’ve removed reads. The output un.trim files are the smallest because those are sequences that we removed because their mate was a terrible read. The absolute worst reads are now gone. It’s partner ended up in those un.trim files. We can confirm this:

$ ls SRR2589044* -lh

-rw-rw-r-- 1 gea_user gea_user 124M Jul  6 20:22 SRR2589044_1.fastq.gz
-rw-rw-r-- 1 gea_user gea_user  94M Jul  6 22:33 SRR2589044_1.trim.fastq.gz
-rw-rw-r-- 1 gea_user gea_user  18M Jul  6 22:33 SRR2589044_1un.trim.fastq.gz
-rw-rw-r-- 1 gea_user gea_user 128M Jul  6 20:24 SRR2589044_2.fastq.gz
-rw-rw-r-- 1 gea_user gea_user  91M Jul  6 22:33 SRR2589044_2.trim.fastq.gz
-rw-rw-r-- 1 gea_user gea_user 271K Jul  6 22:33 SRR2589044_2un.trim.fastq.gz

We’ve just successfully run Trimmomatic on one of our FASTQ files! However, there is some bad news. Trimmomatic can only operate on one sample at a time and we have more than one sample. The good news is that we can use a for loop to iterate through our sample files quickly!

We unzipped one of our files before to work with it, let’s compress it again before we run our for loop.

$ gzip SRR2584863_1.fastq

Building a for loop

Let’s start by reviewing the parts of a for loop and looking to see what the output is.

$ for infile in *_1.fastq.gz
> do
> echo ${infile}
> done

SRR2584863_1.fastq.gz
SRR2584866_1.fastq.gz
SRR2589044_1.fastq.gz

The first for loop above recognized the 3 .fastq files we have in our untrimmed_fastq/and just gave us the file names. The next loop below, just echo’s an additional line.

$ for infile in *_1.fastq.gz
> do
> echo ${infile}
> echo "this is a line that isn't a filename"
> done

SRR2584863_1.fastq.gz
this is a line that isn't a filename
SRR2584866_1.fastq.gz
this is a line that isn't a filename
SRR2589044_1.fastq.gz
this is a line that isn't a filename

Consider the original Trimmomatic command, it had 2 inputs and 4 output files and our loop currently is only aware of 1 of our 2 input files. We need to think of a way to make it aware of all of the others. What do the file names have in common?

$ ls -lh

It looks like there is a common suffix or base to the name. So we can manipulate the content of the variable that we already know called infile and save those manipulated contents to a new variable.

Let’s use basename to demonstrate that we can remove the suffix.

$ basename SRR2584863_1.fastq.gz _1.fastq.gz

SRR2584863

How can we get the output of basename to get stored in a new variable? We can use a special syntax with $() to start a command, run something, and then get back to finishing what it started. Let’s make a new variable and do a subshell of it to see how it works. The output of what is run in () gets stored in prefix.

$ prefix=$(basename SRR2584863_1.fastq.gz _1.fastq.gz)
$ echo ${prefix}

SRR2584863

We can combine the basename command with our existing variable infile to keep the sample name without the suffix. Let’s go to the script we are writing.

$ for infile in *_1.fastq.gz
> do
>  echo ${infile}
>  base=$(basename ${infile} _1.fastq.gz)
>  echo ${base}
> done

SRR2584863_1.fastq.gz
SRR2584863
SRR2584866_1.fastq.gz
SRR2584866
SRR2589044_1.fastq.gz
SRR2589044

Remember your history command? We had a pretty complicated trimmomatic command that we used and we want to substitute the variable in there. Let’s remember what that command was. Who remembers what command shows us things we’ve already done? Look for the trimmomatic command in their history.

$ history | grep trimmomatic

Copy your trimmomatic command and open nano.

$ nano

Nano is unfortunately bad with copying and pasting. You will need to scroll by using arrow keys and use a \ return to get the lines in a readable format.

trimmomatic PE SRR2589044_1.fastq.gz SRR2589044_2.fastq.gz \
               SRR2589044_1.trim.fastq.gz SRR2589044_1un.trim.fastq.gz \
               SRR2589044_2.trim.fastq.gz SRR2589044_2un.trim.fastq.gz \
               SLIDINGWINDOW:4:20 MINLEN:25 ILLUMINACLIP:NexteraPE-PE.fa

Once it is copied in we are now going to convert it to our for loop by replacing the explicit parts with variables.

for infile in *_1.fastq.gz
  do
  base=$(basename ${infile} _1.fastq.gz)
  trimmomatic PE ${infile} ${base}_2.fastq.gz \
               ${base}_1.trim.fastq.gz ${base}_1un.trim.fastq.gz \
               ${base}_2.trim.fastq.gz ${base}_2un.trim.fastq.gz \
               SLIDINGWINDOW:4:20 MINLEN:25 ILLUMINACLIP:NexteraPE-PE.fa:2:40:15
done

Save the text file as trim.sh. The script will be likely be saved in ~/home/your_username/data/dc_workshop/data/untrimmed_fastq.

Return to your terminal and navigate to:

$ cd ~/home/your_username/data/dc_workshop/data/untrimmed_fastq

To make the script executable:

$ chmod +x trim.sh

Go ahead and run the for loop by copying and pasting in the for loop or by running the saved script.

To run the for loop from the script:

$ cd ~/home/your_username/data/dc_workshop/data/untrimmed_fastq
$ ./trim.sh

The ./ tells the server where to find the script and to run it from this location.

It should take a few minutes for Trimmomatic to run for each of our six input files. Once it’s done running, take a look at your directory contents. You’ll notice that even though we ran Trimmomatic on file SRR2589044 before running the for loop, there is only one set of files for it. Because we matched the ending _1.fastq.gz, we re-ran Trimmomatic on this file, overwriting our first results. That’s ok, but it’s good to be aware that it happened.

$ ls

NexteraPE-PE.fa               SRR2584866_1.fastq.gz         SRR2589044_1.trim.fastq.gz
SRR2584863_1.fastq.gz         SRR2584866_1.trim.fastq.gz    SRR2589044_1un.trim.fastq.gz
SRR2584863_1.trim.fastq.gz    SRR2584866_1un.trim.fastq.gz  SRR2589044_2.fastq.gz
SRR2584863_1un.trim.fastq.gz  SRR2584866_2.fastq.gz         SRR2589044_2.trim.fastq.gz
SRR2584863_2.fastq.gz         SRR2584866_2.trim.fastq.gz    SRR2589044_2un.trim.fastq.gz
SRR2584863_2.trim.fastq.gz    SRR2584866_2un.trim.fastq.gz
SRR2584863_2un.trim.fastq.gz  SRR2589044_1.fastq.gz

Exercise

We trimmed our fastq files with Nextera adapters, but there are other adapters that are commonly used. What other adapter files came with Trimmomatic?

Solution

$ ls /opt/conda/share/trimmomatic-0.38-0/adapters/

NexteraPE-PE.fa  TruSeq2-SE.fa    TruSeq3-PE.fa
TruSeq2-PE.fa    TruSeq3-PE-2.fa  TruSeq3-SE.fa

We’ve now completed the trimming and filtering steps of our quality control process! Before we move on, let’s move our trimmed FASTQ files to a new subdirectory within our data/ directory. Always double check that your files moved and that they are of the appropriate size.

$ cd ~/home/your_username/data/dc_workshop/data/untrimmed_fastq
$ mkdir ../trimmed_fastq
$ mv *.trim* ../trimmed_fastq
$ cd ../trimmed_fastq
$ ls -lh

-rw-r--r-- 1 gea_user gea_user 147M May 29 23:53 SRR2584863_1.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user  14M May 29 23:53 SRR2584863_1un.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 144M May 29 23:53 SRR2584863_2.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 381K May 29 23:53 SRR2584863_2un.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 260M May 29 23:55 SRR2584866_1.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 792K May 29 23:55 SRR2584866_1un.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 261M May 29 23:55 SRR2584866_2.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user  14M May 29 23:55 SRR2584866_2un.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 105M May 29 23:56 SRR2589044_1.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 8.4M May 29 23:56 SRR2589044_1un.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 103M May 29 23:56 SRR2589044_2.trim.fastq.gz
-rw-r--r-- 1 gea_user gea_user 276K May 29 23:56 SRR2589044_2un.trim.fastq.gz

Exercise

Now that our samples have gone through quality control, they should perform better on the quality tests run by FastQC. Go ahead and re-run FastQC on your trimmed FASTQ files and visualize the HTML files to see whether your per base sequence quality is higher after trimming.

Solution

In your Jupyter terminal window do:

$ fastqc ~/home/your_username/data/dc_workshop/data/trimmed_fastq/*.fastq*

After trimming and filtering, our overall quality is much higher, we have a distribution of sequence lengths, and more samples pass adapter content. However, quality trimming is not perfect, and some programs are better at removing some sequences than others. Because our sequences still contain 3’ adapters, it could be important to explore other trimming tools like cutadapt to remove these, depending on your downstream application. Trimmomatic did pretty well though, and its performance is good enough for our workflow.

Key Points

• The options you set for the command-line tools you use are important!

• Data cleaning is an essential step in a genomics workflow.
